Úvod » LED podsvícení LED backlight » 7032 6V 1W
7032 6V 1W
SAMSUNG LED Backlight Edge LED Series 7032 Cool white TV Application
7032 6V
SAMSUNG LED Backlight Edge LED Series 7032 Cool white TV Application
Vhodné pro TV Samsung UExxESxxx
Manufacturer : SAMSUNGForward Current (IF ):180mA
Pulse Forward Curren t1 (IFp):mA
Reverse Current (IR):uA
Reverse Voltage (VR):0.7-1.2V (5mA)
Power Dissipation (PD): W
Operatin Tgemperature (Topr): -40 +85C°
Storage Temperature (Tstg): -40 - +100 C°
Soldering Temperature (Tsld): Reflow Soldering:260 C°
Hand Soldering:350C°
for 3secs
Junctio Tnemperature (Tj ): C°
Forward Voltage (VF): 5.9-6.5V(120mA)
Luminous Flux (MCD): 19470-27330MCD(120mA)
Wavelength (nm) : 443-451nm (120mA)
Emissions-farbe Color of Emission :
Color Correlated Temperature (CCT): K
CRI : 80°
Viewing angle : 120°
